Outdoor Rainproof Distribution Cabinet

Street lights, parks, and construction sites need outdoor cabinets. Normal steel cabinets rust in two years. Our Outdoor Rainproof Distribution Cabinet is different. We make a sloped top cover. Rain flows off the sides. The door has an EPDM rubber seal. We did a rain test: 12.5 liters per minute sprayed at the door for 30 minutes. Not a drop got inside.

We use 2.0mm thick galvanized steel or stainless steel 304. The surface is outdoor-grade powder coating. Salt spray test for 500 hours. No rust. For seaside projects, we recommend stainless steel 304. A pier in Zhoushan used our stainless steel cabinet. After five years, it still looks new. All hinges and locks are stainless steel too.

The cabinet has bottom louvers with insect screens. Hot air rises and exits through a hidden top vent. Rain cannot enter. We add a temperature-controlled fan for hot days. The lock is anti-theft with two-point locking. You can add a padlock. Hangzhou Dagang Electric Co., Ltd. has made this product for over a decade. Protection level? IP54 standard, IP65 optional. Lead time for custom size? 15 days. Test report provided? Yes.
